| 型号 | 转速 | 重量 | 长度 | 直径 | 气压 | 最小管径 | 耗气量 | 扭力范围 | 精度 | 锁付能力 | |
| r.p.m | g | mm | mm | Kg/cm² | mm | m³/min | Kgf-cm | % | 机械牙 | 自功牙 | |
| T10PB | 1000 | 480 | 180 | 31 | 6.0 | 5.0 | 0.2 | 0.5—2 | ±3 | M1.0-M2.2 | M1.1-M1.7 |
| T20PB | 1000 | 480 | 180 | 31 | 6.0 | 5.0 | 0.2 | 1—8 | ±3 | M1.7-M3.3 | M1.3-M2.7 |
| T30PB | 1800 | 480 | 180 | 31 | 6.0 | 5.0 | 0.28 | 3—17 | ±3 | M2.2-M4.2 | M1.7-M3.2 |
| T35PB | 2200 | 480 | 180 | 31 | 6.0 | 5.0 | 0.28 | 3—20 | ±3 | M2.2-M4.5 | M1.7-M3.5 |
| T38PB | 1800 | 480 | 180 | 31 | 6.0 | 5.0 | 0.28 | 3—25 | ±3 | M2.2-M4.7 | M1.7-M3.8 |
| T40PB | 1000 | 480 | 180 | 31 | 6.0 | 5.0 | 0.28 | 5—30 | ±3 | M2.8-M5.0 | M2.2-M4.0 |
| T45PB | 800 | 480 | 180 | 31 | 6.0 | 6.35 | 0.3 | 8—40 | ±3 | M3.3-M5.7 | M2.7-M4.4 |
| T48PB | 1700 | 790 | 215 | 39 | 6.0 | 8.0 | 0.55 | 5—45 | ±3 | M2.8-M5.8 | M2.2-M4.7 |
| T50PB | 1400 | 790 | 215 | 39 | 6.0 | 8.0 | 0.55 | 7—50 | ±3 | M2.9-M6.0 | M2.6-M4.9 |
| T55PB | 1000 | 790 | 215 | 39 | 6.0 | 8.0 | 0.55 | 7—65 | ±3 | M2.9-M6.4 | M2.6-M5.4 |
| T60PB | 550 | 790 | 215 | 39 | 6.0 | 8.0 | 0.55 | 15—95 | ±3 | M4.1-M7.0 | M3.1-M6.0 |
| T65PB | 300 | 810 | 215 | 39 | 6.0 | 8.0 | 0.55 | 30—180 | ±3 | M5.0-M9.3 | M4.0-M7.2 |
| T68PB | 250 | 810 | 215 | 39 | 6.0 | 8.0 | 0.55 | 50—280 | ±3 | M6.0-M11.0 | M4.9-M8.7 |
