Product Features
High precision: The intelligent tightening tool can achieve an accuracy of ± 3% - ± 5%, meeting various tightening accuracy requirements.
Long service life: Long service life, maintenance free, easy to operate.
Multiple tightening strategies: one-step, two-step tightening, self tapping, etc., to achieve high-precision tightening at a faster speed, flexibly respond to various application situations, improve tightening quality while increasing tightening cycle, and increase user output. According to customer tightening requirements, customized tightening strategies can be developed.
Multiple communication methods: Supports RS232/485 Modbus RTU communication protocol, with strong scalability, supports multiple IQ inputs/outputs, can customize TCP/IP network ports non-standard, and can quickly build intelligent locking systems.
Data monitoring: data collection and exception handling, real-time display of data during the tightening process, including tightening torque, tightening angle, process time, whether it is qualified, etc. Multi curve display, capable of monitoring the entire tightening process and reducing rework costs caused by tightening failures such as floating locks and slipping teeth.
Data storage: Up to 8 sets of Pests can be set, recording 5 tightening curves and 3000 sets of tightening results.
Adjustable tightening downforce: To meet the application requirements of different materials and tightening strategies, different downforce devices can be set according to different working conditions to meet the corresponding pressure requirements.
Product parameters
Model Applicable Torque Speed (rpm) Weight (kg) Torque Accuracy Voltage (v)
DHSJY-S-018-DP-CT 0.1-0.8 (kgf. cm) Automatic mode: 30-1200 0.4 ± 5% DC: 24-48 Recommended 24
10-80 (mN. m) High speed mode: 30-1800 0.4 ± 5% DC: 24-48 Recommended 24
DHSJY-L-320-DP-CT 0.3-2.0 (kgf. cm) Automatic mode: 30-1200 0.5 ± 5% DC: 24-48 Recommended 24
10-80 (mN. m) High speed mode: 30-1800 0.5 ± 5% DC: 24-48 Recommended 24
DHSJY-ML-014-DP-CT 1.0-4.0 (kgf. cm) Automatic mode: 30-1200 0.6 ± 5% DC: 36-60 Recommended 48
100-400 (mN. m) High speed mode: 30-1800 0.6 ± 5% DC: 36-60 Recommended 48
DHSJY-XL-258-DP-CT 2.5-8.0 (kgf. cm) Automatic mode: 30-1200 0.8 ± 5% DC: 36-60 Recommended 48
250-800 (mN. m) High speed mode: 30-1800 0.8 ± 5% DC: 36-60 Recommended 48
DHSJY-DXL-623-DP-CT 6.3-23.0 (kgf. cm) Automatic mode: 30-1200 1.7 ± 5% DC: 80-120 AC: 60-80 with DC 90V power supply
600-2300 (mN. m) High speed mode: 30-1800 1.7 ± 5% DC: 80-120 AC: 60-80 with DC 90V power supply
DHSJY-TXL-260-DP-CT 20.0-60.0 (kgf. cm) Automatic mode: 30-900 2.3 ± 5% DC: 80-120 AC: 60-80 with DC 90V power supply
2000-6000 (mN. m) High speed mode: 30-900 2.3 ± 5% DC: 80-120 AC: 60-80 with DC 90V power supply
DHSJY-TXL-5150-DP-CT 50.0-150.0 (kgf. cm) Automatic mode: 30-300 2.3 ± 5% DC: 80-120 AC: 60-80 with DC 90V power supply
5000-15000 (mN. m) High speed mode: 30-400 2.3 ± 5% DC: 80-120 AC: 60-80 with DC 90V power supply
DHSJY-TXL-6180-DP-CT 60.0-180.0 (kgf. cm) Automatic mode: 30-300 2.3 ± 5% DC: 80-120 AC: 60-80 with DC 90V power supply
6000-18000 (mN. m) High speed mode: 30-400 2.3 ± 5% DC: 80-120 AC: 60-80 with DC 90V power supply
DHSJY-FXL-1320-DP-CT 100.0-320.0 (kgf. cm) Automatic mode: 30-150 2.3 ± 5% DC: 80-120 AC: 60-80 with DC 90V power supply
10000-32000 (mN. m) High speed mode: 30-150 2.3 ± 5% DC: 80-120 AC: 60-80 with DC 90V power supply
