Fully automatic brushless electric screwdriver
Fully automatic brushless electric screwdriver

Product Features

Fully automatic electric screwdriver, when the screw is locked to the set torque, the clutch will automatically escape, the motor will automatically power off and brake in time, causing the electric screwdriver to stop running.

Adopting a brushless aerospace grade motor, it does not generate dust, has low noise, durability, and does not require maintenance.

Adopting a contactless switch, there is no need to replace consumables, and it has a long service life.

The forward/reverse switch conforms to the dimensions of ergonomics and can be operated with one hand. The torque adjustment is infinitely adjustable by rotating the torque adjustment ring left and right.

All functional electrical interfaces of this electric screwdriver are plug-in structures, and subsequent maintenance does not require a soldering iron. The lightning source board, main control board, brake board, starter board, positive and negative opening board, including the motor and clutch assembly, that need to be replaced can be manually unplugged and replaced in seconds, effectively improving maintenance rates and reducing maintenance costs.



Product parameters


model

Model number

Startup method

Range of torque

Standard speed

Adjustable speed without segments

Length (ground surface)

weight(克)

Applicable screws(mm)

Suitable for screwdriver heads

D-2410

Standard speed

Hand press type

1—10

1000

850-1100

246

515

2.0-3.0

⏀5,S5

D-2416

Hand press type

2—16

1000

850-1100

246

515

2.0-4.0

⏀5,S5

D-2420

Hand press type

3—20

1000

850-1100

246

515

2.0-5.0

⏀5,S5

D-2425

Hand press type

4—25

1000

850-1100

246

515

2.0-5.0

⏀5,S5

D-2410

high speed

Hand press type

1—10

1000

1350-1700

246

515

2.0-3.0

⏀5,S5

D-2415

Hand press type

1.5—15

2000

1350-1700

246

515

2.0-4.0

⏀5,S5
