Product Features

The part foot collector is customized with original American Airlines specialized fans, with high suction, low power, automatic recognition of machine temperature and machine blockage, and automatic shutdown protection in case of high temperature (or part foot blockage, collection box full), without damaging the fan and control parts. The main machine runs continuously for 80000 hours without any abnormalities, and maintenance and upkeep are simple.

In the electronics industry, it is common to see parts feet splashing everywhere, which directly affects 5S. During production operations, when employees cut the feet, the parts feet may fly around, sometimes injuring employees' eyes and causing work injuries, resulting in product short circuits and defects. When employees are cutting the feet, the part feet will be left on the substrate, and sometimes the brush machine cannot remove them, which often causes the machine to short circuit, burn out the host, affect the quality, and cause customer complaints.

Product parameters

Model D-4102 machine size 320 * 320 * 550mm (length * width * height)

Power 0.15-0.35KW (American aerospace brushless fan) Vacuum pressure 5KPA3.5-5KPA

Cutting and suction effect 99.9% control mode, digital display pressure alarm function, automatic detection (motherboard has secondary function)

Input power supply AC 220V 3A ambient temperature 10-50 ℃

Maximum workstations 2-4/4-6 (straw 1.2-2 meters) with a one-year warranty
